超聲波清洗設備操作能代替哪些內容？

作者：admin來源：http://m.0551999.com/時間：2021-06-10

超聲波在液體中傳播，可以使液體與清洗槽在超聲波頻率下一起振動，達到潔凈的效果，在此過程中，液體與清洗槽振動時有自己固有頻率，這種振動頻率被稱為聲波頻率。近年來，隨著清洗行業的不斷發展，越來越多的行業和企業運用到了超聲波清洗機。

When the ultrasonic wave propagates in the liquid, the liquid and the cleaning tank can vibrate together at the ultrasonic frequency to achieve the clean effect. In this process, the liquid and the cleaning tank have their own natural frequency when they vibrate, which is called the acoustic frequency. In recent years, with the continuous development of cleaning industry, more and more industries and enterprises use ultrasonic cleaning machine.

與一般的清洗方式相比，超聲波清洗器具有清洗效果好、操作便捷等優點，因此也深受客戶推崇。好的產品需要合適的操作方法才能達到事半功倍的效果。小編整理了一份關于超聲波清洗器的操作方法，需要的客戶可進行參考。

Compared with the general cleaning method, the ultrasonic cleaner has the advantages of good cleaning effect and convenient operation, so it is highly praised by customers. Good products need appropriate operation methods to achieve twice the result with half the effort. Xiaobian collates an operation method of ultrasonic cleaner, which can be referred by customers who need it.

首先，參照超聲波清洗機安裝說明書連接清洗機的電控柜與主機間的溫控傳感器信號線、超聲驅動線、加熱器控制線等線路，并接通380VAC電源，安裝清洗機的上水管、放水管與溢流排放管，保證機器的正常運轉。

First of all, according to the installation instructions of the ultrasonic cleaning machine, connect the temperature control sensor signal line, ultrasonic drive line, heater control line and other lines between the electric control cabinet and the main machine of the cleaning machine, and connect the 380VAC power supply, install the water supply pipe, water discharge pipe and overflow discharge pipe of the cleaning machine, so as to ensure the normal operation of the machine.

隨后，用戶應向清洗池內加入適量清水，通常情況下液面高度以浸沒將要清洗的零部件為準，一般不超過清洗池的四分之三。在啟動電控加熱開關后，將水溫調節旋鈕上的白色刻度線指向適當的溫度(應為60℃左右)。需要注意的是，清洗機在使用過程中，清洗劑的高溫度不能超過70℃。

Then, the user should add an appropriate amount of clean water to the cleaning pool. Under normal circumstances, the liquid level is subject to the immersion of the parts to be cleaned, generally not more than three-quarters of the cleaning pool. After starting the electric heating switch, point the white mark on the water temperature adjusting knob to the appropriate temperature (about 60 ℃). It should be noted that the maximum temperature of the cleaning agent should not exceed 70 ℃ during the use of the cleaning machine.

當水溫升至40℃左右時，將特定清洗劑加入清洗池中(一般一次5kg左右)，慢慢攪動清水使兩者充分溶解，方可開始清洗之旅。

When the water temperature rises to about 40 ℃, add the specific cleaning agent into the cleaning pool (usually about 5kg at a time), and slowly stir the clean water to fully dissolve the two, then the cleaning journey can begin.

除此之外，超聲波能夠進行精密清洗，但其對泥類的污物處理能力較弱，故預處理中，應盡量將用竹刀先將零部件表面的污垢(如防塵罩外表面會有很多塵土、氣缸體類的零件在其外殼曲線變化處會積留很多厚且易除的油泥)簡單清潔一下，以便延長清洗液使用壽命。

In addition, ultrasonic can carry out precision cleaning, but its ability to treat sludge is weak. Therefore, during the pretreatment, the dirt on the surface of parts (for example, there will be a lot of dust on the outer surface of the dust cover, and there will be a lot of thick and easy to remove oil sludge on the curve change part of the cylinder block) should be cleaned simply with a bamboo knife, In order to extend the service life of the cleaning solution.
